Lined valves and accessories use fluorocarbons such as PFA, PVDF, PTFE, PFA-AS (antistatic), as per customer request.
Fluorinated Ethylene Propylene (FEP) is a resin coating that has a very high chemical and temperature resistance. FEP is highly inert and will withstand exposure to most chemicals and solvents such as Acetic acid, Acetone, Alcohols, Ammonia, Aromatic solvents, Beer, Chlorine, Citric acid, Detergents, Diesel, Fluorinated refrigerants, Fruit juices, Glycols, Hydrogen Peroxide, Hydrochloric acid, Nitric acid, Petrol, Gasoline, Kerosene and Sulphuric acid.
FEP has a high melting point and can be used in environments as high as 200°C (392°F).
FEP is often specified for liquid level measurements applications such landfill leachate monintoring, fuel tank level and chemical storage tanks.
PerFluoroAlkoxy (PFA) offers similar properties to FEP, but is considered more of a premium resin. PFA is preferred when extended service is required in hostile environments involving chemical, thermal, and mechanical stress. PFA offers high melt strength, stability at high processing temperatures, excellent crack and stress resistance, a low coefficient of friction, and more than 10 times the Flex life of FEP.
It has high resistance to creep and retention of properties after service at 500°F (260°C), with useful properties at -320°F (95°C). PFA also meets FDA 21CFR.177.1550.
PFA is used in the same types of applications as those listed above for FEP.
Because of its molecular structure, traditional PTFE cannot be processed by melting, but must be compressed into shapes and heated under pressure (sintered). In contrast, FEP and PFA are melt-processable by conventional thermoplastic processing methods, including injection, transfer, blow, and compression molding and by extrusion.
TetraFluorEthylene-Perfluorpropylene (FEP) is produced by copolymerization of tetrafluoroethylene and hexafluoropropylene. It is a relatively soft thermoplastic with lower tensile strength, wear resistance, and creep resistance than many other engineering plastics. However, it is chemically inert and has a low dielectric constant over a wide frequency range. FEP possesses a very high degree of stress crack resistance, a low coefficient of friction, exceptional dielectric properties, heat resistance, retention of properties after service at 400°F (204°C) with useful properties at -454°F (-270°C), and meets FDA 21CFR.177.1550.
FEP has high transparency (with good transmittance of UltraViolet and visible wavelengths.) It has long term weather ability and excellent resistance to ozone, sunlight and weather. FEP offers the lowest refractive index of all thermoplastics with low light reflection (the same as water.)
Important applications are linings for pipe and chemical processing equipment, and numerous wire and cable applications.
PerFluoroAlkoxy (PFA) offers similar properties to FEP, but is considered more of a premium resin. PFA is preferred when extended service is required in hostile environments involving chemical, thermal, and mechanical stress. PFA offers high melt strength, stability at high processing temperatures, excellent crack and stress resistance, a low coefficient of friction, and more than 10 times the Flex life of FEP.
It has high resistance to creep and retention of properties after service at 500°F (260°C), with useful properties at -320°F (95°C). PFA also meets FDA 21CFR.177.1550.
PFA is used in the same types of applications as those listed above for FEP.
Aira 4Matic Global Valve Automation Pvt. Ltd. is one of the best manufacturer and exporter of PTFE Lined Ball Valves, Weir Type Lined Diaphragm Valves, Lined Butterfly Valves and Lined Plug Valves.
Plot no. 174, Shiv Shakti Estate, Near Prince Hotel, Narol Road Ahmedabad - 382 405 Gujarat. India.
